One-Touch Fastener - Pins 33923

What is...

Installation

Standard Mount

Recessed Mount

Prepare a tapped hole according to the thread of the pin. Ensure a counter bore is machined to depth h2 to complete pin installation.

Mounting Typeh1h2
+0,1		d3
33923.W0006StandardM4x0,7--
33923.W0006RecessedM4x0,70,57
33923.W0008StandardM5x0,8--
33923.W0008RecessedM5x0,80,59
