Wixroyd Quick Plug Coupling - Cam Locking 64775 - 64780
Features
Operating Principle
When the male Quick Plug Coupling is fully inserted into the receiver and actuated, the internal spring is compressed to clamp the shaft.
Operating Instructions
Insert the shaft into the keyway of cam receiver.
Rotate the shaft block 90° to clamp the element. An audible click can be heard when clamped. For unclamping, reverse these steps.
Repeatability
Prepare male and female fittings for highly accurate locating. Repeatability of ±0.08 is achievable.
Installation
How to mount Shaft Coupling Clamp
How to mount Receiver (shaft mount)
How to mount Receiver (plate mount)
Applications
Changes of Thrust Pads
Changes of Riser
General Guidance
Notes
Pay attention to the direction of holes for Spring Pins.
