ReLock 8-Station Vice System 19762 - 19768
What is...
The ReLock 8-Station's compact and lightweight unibody design is perfect for horizontal machining centres. The unibody is manufactured from 80,000 PSI ductile cast iron and the guide parts are flame hardened and precision ground to accuracies of ±0005". It's also ideal for use with rotary indexers on vertical machining centre applications.
General Guidance
Single Station Conversion Plate
Easy mounting instructions for the Single Station Conversion Plate 19769 on a ReLock 8-Station Vice.
Step 1
Crank bottom jaw toward center of vice. Mount single station conversion plate 19769 to the back carrier jaw as shown
Step 2
Crank bottom jaw down until the single station conversion plate touches baseplate. Mount the single station conversion plate to the baseplate
Technical Specs
Universal Baseplate for 4” ReLock 8-Station Vice
Details of baseplate included with vice no. 19762.W0040.
400mm Baseplate for 4” ReLock 8-Station Vice
Details of baseplate included with vice no. 19762.W0041.
Universal Baseplate for 6” ReLock 8-Station Vice
Details of baseplate included with vice no. 19762.W0060.
400mm Baseplate for 6” ReLock 8-Station Vice
Details of baseplate included with vice no. 19762.W0061.
Universal Baseplate for 8” ReLock 8-Station Vice
Details of baseplate included with vice no. 19762.W0080.
