Cam Latch Flexi-System
insert driver - fixed grip
A1003 Cam Latches - Flexi-System
insert driver - fixed grip - zinc, material: Die cast zinc
Order No.
A1003.AW0360
Finish
Black Coated
Insert driver
3mm Double Bit
d1
28
h1
6
lh
18
£ 2.42 per unit (click for quantity discounts)
Ready to despatch 243
Need more? Please call us.
Need more? Please call us.
| Units | Price/unit after discount | Applied Discount |
| 1-19 | £ 2.42 | 0% |
| 20-49 | £ 2.18 | 10% |
| 50-99 | £ 2.06 | 15% |
| 100-499 | £ 1.82 | 25% |
| 500+ | £ 1.57 | 35% |
Technical & Application
Material
Body & insert: die cast zinc. Finished in chrome plate or black powder coating.
Insert fitted with O'ring to achieve IP54 rating. Internal spring provides 1,5mm torsion.
Supplied with: Nut: steel, zinc plated.
Sealing washer: PU and rubber.
Not supplied: CAM nor KEY - order separately.
Technical Notes
Order cam and key separately.
Cams: see suitable cam A0203, A0224 and A0240. Select "without projection" cam type.
Dimensions ch and cl relate to cam. Use formula to calculate ch (required cam off-set), and refer to cam selection chart;
ch = h - lh where;
ch = required cam off-set/height.
h = grip length (distance between inside of latch face and front of cam).
lh = body length of cam latch/lock to be used (see product table below).
Keys: see A0102.
Rods & Guides: to achieve 3-point latching - A0303, A0321, A0325.
Important Notes
Extended body version - A1251.
Sold subject to pack quantity.
